Size (cm / inches) 122 x 45 x 95 cm / 48.03 x 17.72 x 37.40 in
Weight (kg / lb) Without shaft 56.8 kg / 125.22 lb
With shaft 74.5 kg / 164.24 lb
Shaft
Ø (mm / inches)
Length (m / feet)
Ø10 / 0.39 Flexible Shaft with Outer Casing
31 / 101.7
Rotating max. speed (rpm) 2250
Voltage and power rating (V/kW) 240 V / 1.5 kW
Input Power Electric, 1-phase
Input 220-240VAC / 50-60 Hz / 16 A
IP Class 54
Diameter (mm / inches) DN50-200 / 2-8
Other technical information
Adjustable speed control
Direction Switch
Foot Pedal (OPC)
Emergency Stop
Electronic Safety Switch
PU Foam Wheels, diameter 400mm
Robust steel frame
Drum lock
